P/N: 87999 - UPC: 834537000017

• 14“ Diameter
• Overall Printer Height: 24” tall
• Overall Printer Weight: 18 Pounds
• Power Requirements: 100-240 AC 350 Watts (Selectable on power supply input)
• Shipping Dimensions: 30“ X 16” X 16“ Box weighing 27 pounds

• Maximum Printable X/Y Area: 6” Diameter (150mm)
• Maximum Printable Square Size: 4 1/8“” (106mm)
• Maximum Printable Z Height: 9 1/4“ (235mm)

• Avg. Print Speed: 30-60mm/s
• Max Movement Speed: 300mm/s
• Max Hotend Temperature: 245c
• Max Heated Bed Temperature: 120c
• Part Cooling Fan

Included (G Code Controlled)

Clean CNC Room

Owner: The Bodgery

Donated by: Ben Heckendorn (2016)

• Up-front LCD panel to show the status of your print
• On-board SD card (included) for storing up to 4GB of print files (that's an average of apx. 2700 prints!!!)
• Heated build surface for ABS printing
• High speed positioning (up to 300mm/s)
• 6” diameter by over 9“ tall cylindrical build volume (apx. 175 cubic inches) or 5” Square by 9“ tall box shaped build volume
• Comes standard with a .5mm nozzle
• Optimized for ABS from the start, no need to add on or upgrade like many other machines
